TEMPOMATIC MIX 4 electronic mixer

Ref. 490101
Plug-in mains supply
  • TEMPOMATIC MIX 4 electronic mixer
  • TEMPOMATIC MIX 4 electronic mixer
  • TEMPOMATIC MIX 4 electronic mixer
TEMPOMATIC MIX 4 electronic mixer

DESCRIPTION

TEMPOMATIC MIX 4 electronic mixer

Ref. 490101

Deck-mounted electronic basin mixer:

230/6V plug-in mains supply.

Reduced-stagnation solenoid valve and electronic unit integrated into the body of the mixer.

Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.

Scale-resistant flow straightener.

Duty flush (~60 seconds every 24 hours after last use).

Active, infrared presence detection, sensor at the end of the spout optimises detection.

Chrome-plated metal body.

Cap fixed in place by 2 concealed screws.

PEX flexibles F3/8" with filters and non-return valves.

Fixing reinforced by 2 stainless steel rods.

Anti-blocking security.

Side temperature control with standard lever and adjustable maximum temperature limiter.

Suitable for people with reduced mobility.

10-year warranty.

ADVANTAGES

Total hygiene: no manual contact

90% water savings

Recessed mains supply

Anti-bacterial proliferation duty flush

TECHNICAL CHARACTERISTICS

TEMPOMATIC MIX 4 electronic mixer

Ref. 490101
Technology Electronic
Flow rate 3 lpm
Connector F3/8"
Supply 230/6V mains supply (plug-in)
230/6V plug-in mains supply
Drop Height 75 mm
Spout Length 110 mm
Installation: Deck-mounted
TEMPOMATIC MIX 4 electronic mixer - scheme
