DESCRIPTION
Wall to floor 90¼ grab bar white steel left
Ref. GW11 12 03 00No built- in angle bar with three points of support located on the endings.
The bar consists of a carbon steel tube with 32 mm of diameter and 1.5 mm of thickness.
The tube is bended on ÒLÓ shape 90 degrees.
The three mounting flanges are made of zinc-plated steel plate with anticorrosion treatment of 2.5 mm of thickness and 75 mm of diameter.
The endings of the tube and the mounting flanges are threading M10.
Mounting flanges have three holes for wall attachment and snap flange covers with 0.5 mm of thickness.
The white epoxy steel assembled unit has suitable resistance to corrosion.
The bar is fixed to the wall and the floor by means of 6 nylon wall plugs (10X60) and steel screws (6X60).
Grab bar will support loads in excess of 120Kg if properly installed
